Architectural Planning Drawings Requirement for Planning Permits in Victoria: Your Essential Guide

In Victoria, undertaking any form of building work on your property typically requires you to navigate a regulated process of permits and approvals.

Precise and comprehensive architectural planning drawings play a critical role in obtaining a planning permit. These drawings are essential as they detail your proposed development’s design, layout, and compliance with local regulations.

Your architectural drawings, prepared by a qualified architect or draftsperson, serve as a visual and technical blueprint for your project.

To ensure a smooth permitting process, these drawings must include all mandatory details.

The site plan, with a scale of at least 1:500, forms a part of this documentation, illustrating the scope and impact of your planned construction in relation to its surroundings.

Navigating the permitting landscape requires an understanding that a planning permit may be needed before a building permit can be issued.

The Building Act 1993 mandates that any building permit must align with the relevant planning permit, which encompasses conditions and endorsed plans.

As you prepare your application, be aware that the building work should not only meet structural adequacy but also reflect the health, safety, and amenity standards prescribed by the Victorian Government Building Regulations.

Overview of Planning Permits in Victoria

In Victoria, obtaining the correct permits is a critical step in the property development process. Your understanding of these permits and adherence to local regulations ensures a legally compliant and successful project.

Understanding Planning Permits

A planning permit is your legal authorisation to proceed with the use or development of land in Victoria. This permit assesses the potential impacts of your proposal against the relevant planning scheme.

The local council assesses and issues these permits, and requirements can vary between councils.

When preparing your architectural planning drawings, ensure they align with council regulations and clearly depict the proposed design, as they form a crucial part of your application.

Distinction Between Planning and Building Permits

It’s essential to distinguish between a planning permit and a building permit.

A planning permit focuses on the appropriate use and development of land, often scrutinising the broader impact on the environment, community, and compliance with planning schemes.

In contrast, a building permit, issued under the Building Act 1993, pertains strictly to construction matters—confirming that your design complies with building regulations, including structural integrity and safety standards.

Remember, you may require both permits before you start any work on the property.

Pre-Application Process

When you’re starting out with your building project, grasp the importance of the pre-application process. It lays the groundwork to ensure that your application is compliant, recognised by the council, and has a higher chance of success.

Initial Research

Before anything else, you need to perform diligent initial research.

Familiarise yourself with the local planning scheme and check if your project requires a planning permit or falls under an exemption.

Key points to investigate are:

• Zoning regulations and overlays
• Specific controls that apply to your land
• Local policies which might influence your proposal

Consulting With Council

Your interaction with the council‘s planning department is vital.

A council planner can offer insight into:

• Whether your proposal requires a permit
• If the proposal is permissible
• What extra information is necessary for your application
• How your application should be structured

Important Contacts:

• Local Council Planning Department: [Insert Phone Number]
• Email Address for Inquiries: [Insert Email Address]

Pre-Application Meetings

It’s prudent to request pre-application meetings with a council planner. These sessions allow you to:

• Discuss your proposal in detail
• Receive feedback on the likelihood of obtaining a permit
• Understand any concerns that might arise during public notice

Documenting the advice received during pre-application meetings and incorporating it into your proposal can streamline the process once you formally lodge your application.

Application Preparation

When preparing your application for a planning permit in Victoria, it’s essential to gather all required documentation and ensure that your site plan and architectural drawings adhere to local regulations.

This meticulous preparation will facilitate the assessment process and increase the likelihood of a favourable outcome.

Documents and Information Required

For your planning permit application, you’ll need to submit a comprehensive set of documents. These typically include:

• An application form, completed with your details and the specifics of your proposal.
• A written report explaining the details of your project, how it complies with the Planning Scheme, and an assessment against relevant policies and standards.
• Title documents for the land, including a current Certificate of Title.
• Additional reports such as a shadow diagram or heritage impact statement, where applicable.

Here’s a checklist for your reference:

Document Type	Description
Completed Application Form	Required for initial lodgement.
Certificate of Title	Not older than three months to ensure current owner details.
Site Context Analysis	Including photos and description of site and surrounds.
Existing Conditions Plan	Illustrating the current state of the site.
Written Submission/Report	Explaining your proposal in detail.
Specialist Reports (if required)	Reports like shadow diagrams or arborist reports.

Site Plan and Architectural Planning Drawings

Your application must include a detailed site plan and architectural design drawings.

These drawings are crucial as they provide a clear representation of your intended project.

Your site plan should be drawn to a recognized scale, typically 1:200 or 1:500, and must show:

• The location and dimensions of the existing and proposed developments.
• The layout of the site, including building envelopes, setbacks, and access points.
• Specifications related to materials, heights, and external finishes.

The architectural drawings should be comprehensive and include:

• Floor plans.
• Elevations.
• Sections.

These should show the design in context, including neighbouring buildings (where relevant) to demonstrate compliance with relevant privacy and overshadowing standards.

Ensure that these plans are thoroughly detailed, as inaccuracies can lead to delays or refusal of your permit application.

Submitting a Planning Permit Application

When applying for a planning permit in Victoria, presenting a well-prepared application to your local council is critical. Ensure you have all the necessary supporting documentation to streamline the process and avoid delays.

Application Submission to Council

To submit your application, contact your local council‘s planning department. They will guide you through the process, indicating if your proposal requires a permit and if it aligns with local planning regulations. You will need to:

1. Fill out the permit application form provided by the council.
2. Pay the applicable application fees, which vary depending on the council and the scope of your project.
3. Submit your application either online through the council’s website or in person at the council offices.

Make sure to keep a record of the submission receipt as proof of your application lodgement.

Supporting Documentation

Accompanying your permit application, the following documents are typically required:

• Recent Certificate of Title: Proves ownership and details any covenants or easements affecting the land.
• Plan of Subdivision: If applicable, include a copy showing the division of the land.
• Detailed Site Plan: To be clear and drawn to scale, it should include the full dimensions of the lot, location of existing and proposed structures, and distances from boundaries.
• Development Plans: Detailed architectural plans showing the design and layout of proposed structures or alterations.

You may also need to submit:

• A planning report.
• Shadow diagrams.
• Other documentation as advised by your council.

Each council may have its specific requirements, so it’s essential to verify the details with them directly.

The Assessment Process

When you apply for a planning permit in Victoria, your submission undergoes a thorough and multi-step assessment process. This includes reviews by the council, public notifications, consideration of objections, and possibly referrals to other authorities for their input before a decision is made.

Council’s Initial Review

Initially, your local council meticulously examines your architectural planning drawings and supporting documents. They verify compliance with local planning schemes and ensure that all necessary information is presented.

If anything is lacking or requires clarification, you’ll be notified to provide additional details.

Advertising and Public Notice

Once deemed complete, your application is usually advertised to inform the public, providing an opportunity for any person to view the plans and make a submission.

You must display a public notice on the site and the council may request further advertising in local newspapers or online platforms. This stage is pivotal as it invites community participation.

Objections and Submissions

Public engagement brings about objections and submissions. If your proposal receives objections, they are formally recorded, and you will be informed.

You may have to address the concerns raised, which can involve modifying your plans or negotiating solutions.

Referrals and Decision Making

Some applications require referrals to external authorities—such as the Department of Environment, Land, Water and Planning—especially if they involve significant developments or environmental concerns.

Following referrals and considering all objections and submissions, the council then makes an informed decision on whether to grant or refuse the permit.

The decision process may vary in complexity based on the nature and scale of your project.

Planning Permit Approval and Conditions

Before commencing your building project in Victoria, you need to secure a planning permit, ensuring compliance with local regulations and specific conditions.

Permit Decisions

Once you submit your application, the council will decide to grant or refuse your planning permit based on local planning schemes.

If granted, your permit will come with conditions that must be strictly adhered to. These conditions outline the parameters of the development and may include an amendment requirement if changes to the original proposal are necessary.

Development Conditions and Endorsements

The permit will include a list of conditions and often require endorsement of the plans.

It’s essential that all development conditions, which can dictate everything from design specifications to environmental protections, are met.

These conditions form part of the legal document which is the permit itself. Failure to comply may result in legal action or invalidation of the permit.

Legal Obligations

By law, it’s your responsibility to obtain the necessary planning permit and ensure your building work is consistent with this permit.

This legal consent from the local council can prevent costly and time-consuming legal challenges.

An amendment to a permit can be sought but will also be subject to council approval and may be accompanied by additional conditions.

Amendments to a Planning Permit

When you wish to make changes to an approved project, your planning permit may need to be amended. This amendment process can cater to both minor tweaks and significant overhauls of your original plans.

Minor Amendments

For slight adjustments that don’t materially alter the scope of your development, you can seek minor amendments to your planning permit. These may include:

• Changes in materials or finishes: You might wish to alter the external cladding of your building or the types of finishes used internally.
• Minor modifications to the design: Small changes to window placement or internal room sizes.
• Extension of time: If you’re unable to commence or complete the project within the required time frames, you can apply for an extension.

Remember, the discretion for what constitutes a ‘minor’ change is ultimately held by the relevant council.

Major Revisions

Should your project undergo significant alterations that substantially change the originally approved plans, you’ll need to apply for major revisions to your planning permit. Significant changes often include:

• Alterations to building layout: Modifying the overall footprint or adding/removing floors.
• Changes to the use of land: Switching from residential use to commercial, for example.
• Addition or removal of conditions: This may involve negotiating new terms with the planning authority.

These types of amendments may require a more comprehensive assessment and potentially, a new round of community consultation, as dictated by the planning authority.

Building Permit Application

Before you begin any building work in Victoria, you must ensure that you obtain the necessary permissions. The core of this process is the building permit application, which must be completed accurately to adhere to state regulations and standards.

The Role of Building Surveyors

A registered building surveyor is integral to the building permit application process. You will need their expertise to review your architectural plans and ensure they comply with the Building Regulations 2018.

Your chosen surveyor will be responsible for assessing whether your plans meet the necessary building standards and codes. Their approval is essential before your project can legally proceed.

Building Regulations and Compliance

When you submit your building permit application, it needs to align with the current Building Regulations 2018. This ensures your building work will be safe and compliant with the established planning controls.

Your application should detail how the construction will adhere to these regulations, covering aspects such as safety measures, structural adequacy, and accessibility.

Remember, while a building surveyor facilitates the assessment of your building permit application, it is your responsibility to ensure that all the details are correct and in accordance with relevant Victorian building laws and codes.

Inspections and Certificates

In Victoria, oversight of your building project is integral to ensuring it aligns with local standards. You will encounter mandatory inspections during construction and a pivotal document upon completion.

Mandatory Building Inspections

Throughout the construction of your project, mandatory building inspections are required at key stages to ensure compliance with the Building Act 1993 and the Building Regulations.

It is your responsibility to arrange these inspections with a registered building surveyor. The surveyor will assess various aspects of your building work.

Following these inspections, the surveyor must be satisfied that the work meets legislative requirements before you can proceed to the next stage of construction.

Certificate of Final Inspection

Upon the completion of some building works, a Certificate of Final Inspection is issued. This document signifies that the mandatory inspections have been carried out and the building works meet the relevant standards.

It’s pivotal to note that this certificate is different from an occupancy permit, which is required for new buildings.

An occupancy permit is necessary before you can safely occupy a new building, whereas the Certificate of Final Inspection is required to ensure the completed works satisfy the building regulations.

Sustainable Development and Compliance

When seeking a planning permit in Victoria, you must adhere to sustainable design requirements and ensure your development complies with the relevant bushfire safety standards.

Sustainability Measures

Your architectural planning drawings play a critical role in meeting Victoria’s sustainability criteria.

It is imperative for your development to align with sustainable building practices. This includes resource-efficient designs that minimise environmental impact and enhance energy efficiency.

You need to integrate sustainability measures such as:

• Solar passive design principles
• Water-saving fixtures
• Efficient waste management systems

These initiatives support Victoria’s Metropolitan Strategy, Plan Melbourne 2017-2050, and help mitigate climate change effects by fostering environmentally responsible developments.

Bushfire Attack Level Rating

In bushfire-prone areas, your architectural planning drawings must include a Bushfire Attack Level (BAL) rating assessment.

This assessment determines the potential exposure of the building to ember attack, radiant heat, and direct flame contact.

Your compliance with Australian Standards AS 3959-2018 is non-negotiable; it outlines the construction provisions for buildings in bushfire-prone areas.

The following table exemplifies the BAL ratings and the corresponding construction responses:

BAL Rating	Construction Response
BAL-LOW	Minimal additional construction requirements
BAL-12.5	Specific construction to protect against ember attack
BAL-19	Increased construction measures for ember and radiant heat protection
BAL-29, BAL-40 & BAL-FZ	Incrementally more stringent construction requirements for higher potential exposure

Your planning drawings should reflect the appropriate BAL rating to ensure that the development stands up to potential bushfire threats while conforming to the necessary Australian Standards.

Post-Approval Requirements

After obtaining your planning permit in Victoria, it’s crucial to carefully adhere to the conditions set out in the permit. Fulfilment of these conditions is a prerequisite for proceeding with your development project.

Meeting the Permit Conditions

Your planning permit comes with specific conditions that must be met before construction can commence. These conditions are designed to ensure that your project complies with local laws and regulations.

It’s your responsibility to:

• Review all permit conditions: Carefully go through each condition outlined in your permit.

• Prepare the necessary documents: Submit all plans, drawings, or documents as required by the conditions for approval.

• Obtain endorsements: Certain conditions may require specific endorsements from council or other authorities to proceed.


Occupancy and Safety Requirements

Before a building can be occupied, you must obtain an occupancy permit. This permit is proof that the building is safe to use and compliant with regulations.

To secure an occupancy permit, ensure the following:

• Complete all works: The building should be finished in accordance with the approved plans.

• Safety checks: All necessary safety measures, including fire safety, must be in place and certified.

• Insurance: Verify that you have the appropriate insurances required by law, which may include public liability insurance or construction insurance.


Keep in mind that non-compliance with permit conditions or failure to secure an occupancy permit can lead to penalties or enforcement actions. Always ensure that all requirements are thoroughly addressed to avoid potential setbacks.

Legal and Professional Considerations

When seeking planning permits in Victoria, you must adhere to specific legal frameworks and uphold professional standards. Compliance with relevant legislation ensures your architectural plans meet state requirements, while professional conduct and insurance protect your interests and those of your clients.

Architectural and Building Legislation

Your architectural planning drawings fall under two critical pieces of legislation: the Building Act 1993 and the Planning and Environment Act 1987.

As a professional, you must understand that the Victorian Building Authority (VBA) oversees the enforcement of these regulations.

• Building Act 1993: This mandates that your drawings comply with building regulations and codes.
• Planning and Environment Act 1987: Requires that the use, development, and protection of land align with stipulated planning schemes.

To move forward with development, your project may need a planning permit from the local council before obtaining a building permit.

Ensure that the proposed works are consistent with any planning permits issued to prevent future legal complications.

Professional Conduct and Insurance

As an architect licensed by the Architects Registration Board of Victoria (ARBV), your conduct is regulated to uphold industry standards.

• Professional Conduct: Ensure your plans are ethical, accurate, and follow the guidelines prescribed by the ARBV.
• Insurance: Maintain appropriate levels of professional indemnity insurance to safeguard against potential liability.

Navigating these considerations meticulously will position your project for a smoother permit acquisition process and align with the expectations of your profession in Victoria.

Financial Considerations

When seeking a planning permit for your architectural project in Victoria, you need to be mindful of the various financial obligations involved. These can include not only application fees and permit expenses but also additional levies and potential rebates.

Application and Permit Fees

Your initial expense in the permit application process will be the application fee.

This fee varies depending on the scope and cost of the proposed development and is required when you lodge your application with the local council.

Once your planning permit is approved, you will then proceed to apply for a building permit.

The cost of the building permit includes a fee that contributes to the Building Permit Levy, which is based on the cost of the proposed building work.

Here is a simple breakdown of the possible fees you may encounter:

• Planning Permit Application Fee: Subject to the local council’s schedule.
• Building Permit Fee: Calculated based on the total cost of construction, which includes a fixed application fee and an additional variable fee.

Levies and Rebates

Beyond the basic fees, you are required to pay a Building Permit Levy before the building permit is issued.

The levy rate is calculated as a percentage of the total cost of building work and contributes to the building control system and building industry regulation.

Regarding rebates, they are not commonly available for the standard permit process fees and levies.

However, certain developments might qualify for specific concessions or rebates based on sustainability measures or other criteria set by the local or state government.

It is essential that you consult the Victorian Building Authority or your local council for the exact figures concerning these financial responsibilities, as these can have a significant impact on the overall budget of your construction project.

Engaging with Stakeholders

When preparing architectural planning drawings for a planning permit in Victoria, successful stakeholder engagement is crucial. This involves effective communication strategies and collaboration with various parties involved in the planning process.

Communication with Neighbours

Your project’s success can be influenced by how well you communicate with your neighbours.

It is your responsibility to inform them of your proposed developments as they may be directly affected.

• Discuss Plans Early: Aim to discuss your project with neighbours before formal plans are submitted. This fosters a cooperative environment and can pre-empt objections.

• Notification: Local councils will typically require that neighbouring properties are notified of your application, giving them an opportunity to review and comment.


Being open and considerate in your approach can minimise conflicts and facilitate a smoother planning process.

Working with Designers and Surveyors

Engaging with professional designers and surveyors is a pivotal element of preparing your planning application.

• Designers:

  • Architects are instrumental in creating your planning drawings. Ensure to discuss your vision and practical requirements with them thoroughly.
  • The client-architect agreement must clearly outline the project’s scope, specific requirements, and timeframes.
• Surveyors:

  • A private building surveyor can help certify your plans and ensure they comply with relevant building regulations.
  • Alternatively, engagement with a municipal building surveyor can offer additional oversight and localised knowledge of requirements.

By working collaboratively with these professionals, you ensure that planning drawings are not only compliant but also tailored to facilitate permit approval.

Special Cases and Exemptions

When seeking a planning permit in Victoria, you may come across particular scenarios where the standard permit process does not apply. Understanding these cases will help you navigate the planning permit process with greater ease.

VicSmart Applications

VicSmart is a streamlined assessment process for certain types of low-impact planning permit applications.

• The criteria for a VicSmart application include specific requirements such as:

  • The proposal aligning with predefined classes of application.
  • A process time of typically 10 business days.
  • A requirement for limited information, ensuring a faster decision.

Key Entities Covered:

• VicSmart: Shortened processing times and reduced information requirements.

Planning Scheme Exemptions

Not every development requires a planning permit. Planning scheme exemptions exist to simplify the process for certain low-impact or compliant activities.

• You should carefully review the planning scheme to understand if your project meets the criteria for an exemption. Typical exemptions might include:

  • Small, minor buildings and works that comply with the regulations.
  • Certain changes of land use when the impact is negligible.
  • Specific repairs and routine maintenance which do not alter the land use or buildings significantly.

Remember: Always check Clause 18 and related clauses for transport provisions, as well as Clauses 65.01 and 65.02 that detail notice and review exemptions.

Key Entities Covered:

• Exemption: Criteria under which certain development activities do not require a planning permit.
• Planning Schemes: The legal documents that set out rules governing land use and development.

Dispute Resolution

When facing disputes over architectural planning drawings for planning permits in Victoria, it’s essential for you to know the formal pathways available.

Building Appeals Board

The Building Appeals Board (BAB) is an independent statutory body that reviews building and plumbing decisions, including disputes related to architectural planning drawings and permits.

• If you’re dissatisfied with a decision made by your local council or a private building surveyor, you can lodge an appeal with the BAB.

• Key facts about the Building Appeals Board process include:

  • Filing an appeal: You must submit your application within 30 days of the council’s decision.
  • Hearings: The BAB conducts hearings to review evidence and make determinations on the dispute.

Mediation and Conflict Resolution

Mediation is a less formal and often less adversarial approach to resolving planning disputes.

• In Victoria, you can access mediation services through the Victorian Civil and Administrative Tribunal (VCAT) or other alternative dispute resolution providers.

• During mediation, all parties involved – permit applicants, responsible authorities such as councils, and objectors – come together to seek a mutually agreeable solution.

• Advantages of mediation include:

  • Cost-effective: Generally less expensive than legal proceedings.
  • Time-saving: Can resolve disputes more quickly than through court or tribunal hearings.

It’s important for you to keep a comprehensive record of all communications and to consider engaging professionals such as lawyers or mediators if you are unable to resolve the dispute on your own.

Frequently Asked Questions

Navigating planning and building permits in Victoria? Your questions about the architectural plan requirements for planning permits are addressed here.

What types of construction require a planning permit in Victoria?

You’ll need a planning permit in Victoria for certain types of building work, land use or development. This includes commercial, industrial, and some residential construction. Check with your local council as requirements can vary.

Are there any exemptions from obtaining a building permit in Victoria?

Yes, there are exemptions. Minor structures like garden sheds and some fences might not require a permit. Always confirm with the Victorian Building Authority or your local council for the specific exemptions applicable.

What is the checklist for a building permit application in Victoria?

Your building permit application checklist should include detailed architectural and structural drawings, a site plan, and other documents such as engineering computations and soil reports. Ensure all documents comply with current regulations.

Can I view my neighbour’s building plans in Victoria?

In certain circumstances, you’re allowed to view and make submissions about your neighbour’s building applications during the public notification process. For details on your specific situation, contact your local council.

Is it permissible to submit self-drawn plans for a building permit in Victoria?

Self-drawn plans may be submitted if they meet all necessary criteria and professionally communicate the required information. However, engaging a registered draftsperson or architect is recommended to ensure compliance and quality.

Which documents must accompany a building permit application in Victoria?

Your application should be accompanied by site plans, elevations, sections, and an allotment plan. The requirements may also include specifications, a copy of the title, relevant council consents, and energy rating reports.

Wrapping Up

Planning drawings serve as the blueprint for successful architectural projects, providing essential guidance for construction and design. Understanding the significance of these drawings is crucial for ensuring a smooth and efficient building process. If you have any questions or need further clarification on planning drawings, do not hesitate to contact SQM Architects. Our team of experts is ready to assist you in realizing your architectural vision.
