If you are planning to build stairs or install handrails in your home or business in Australia, it is important to understand the relevant Australian Standards. Compliance with Australian standards for stairs and handrails ensures the safety and accessibility of your stairs and handrails for all users, including those with disabilities.
The Australian Standard for stairs, AS1657-2018, outlines the requirements for the design, construction, and installation of stairs in all types of buildings. These requirements include the minimum width of stairs, the maximum height and depth of each step, and the minimum clearance between rails. The standard also specifies the minimum width of landings and the distance between landings.
Similarly, the Australian Standard for handrails and balustrades, AS1428.1-2009, provides guidelines for the design and installation of handrails and balustrades to ensure they are safe and accessible for all users. The standard specifies the height of handrails above the floor or stair nosing, the strength and durability of materials used, and the clearance between handrails and walls or other surfaces. Compliance with these standards is essential to ensure the safety and accessibility of your stairs and handrails for all users.
Australian Standards for Stairs and Handrails
When it comes to building stairs and handrails in Australia, there are specific standards that must be followed to ensure compliance with regulations. These standards are set out in the Australian Standard AS1657-2018 and are designed to ensure the safety of those using the stairs and handrails.
How to gain professional insights for FREE, no strings attached
Unsure about your next building project? Get expert advice, no strings attached! Take advantage of our FREE consultation at SQM Architects. We’re here to answer your queries and bring clarity to your vision. With our transparent process and reputable track record, your project is in capable hands.
Stairs
According to AS1657-2018, every stairway must have at least one handrail, and a handrail on each side for stairways wider than 1000mm. Stairs landing must have a minimum live loading of 2.5 kPa and a minimum point loading of 1.1 kN applied on a 100mm × 100mm pad. The standard also specifies the maximum and minimum riser heights and tread depths, as well as the width of the stairway.
Handrails
The height of a handrail above the floor or the nosing of a stair tread shall be between 900mm and 1100mm, according to AS1657-2018. Where the fall from height is significant, it is recommended to increase the height of the guardrail to at least 1000 mm. Where circular metal handrails are provided, the external diameter shall be 30mm to 65mm. The standard also specifies the clearance between the handrail and any adjacent surface, as well as the maximum distance between handrail supports.
Compliance
It is important to ensure that any stairs and handrails being built are compliant with the relevant Australian standards. Failure to comply with these standards can result in fines, legal action, and serious injury or death. Compliance with the standards can be achieved by engaging a qualified engineer or builder who is familiar with the regulations.
Stairway Design and Dimensions
When designing stairs for your building, it is important to adhere to Australian standards to ensure the safety of the users. This section will cover the various dimensions and design considerations that must be taken into account when constructing stairs and handrails.
Stairway Dimensions
Stairways must be designed to take loading forces in accordance with AS/NZS 1170.1. Stairways must have not more than 18 and not less than 2 risers in each flight. The going (G), riser (R), and slope relationship quantity (2R + G) must comply with Table 3.9.1.1 of the National Construction Code (NCC). The minimum tread depth is 240mm, and the minimum riser height is 115mm.
Treads and Risers
Treads must have a minimum depth of 240mm and a maximum rise of 190mm. The nosing must be between 5mm and 25mm. Risers must have a minimum height of 115mm and a maximum of 190mm.
Staircases and Flights
A staircase is a series of flights of steps with landings provided at appropriate intervals. Flights and landings must be level and have a minimum width of 900mm. The minimum headroom clearance above the nosing of treads must be 2000mm.
Ramps and Platforms
Ramps must have a maximum slope of 1:8 and a minimum width of 1200mm. Platforms must have a minimum length of 1500mm and a minimum width of 1200mm.
Guardrails and Handrails
Every stairway must have at least one handrail and a handrail on each side for stairways wider than 1000mm. Handrails must be between 900mm and 1100mm in height. The external diameter of circular metal handrails must be between 30mm and 65mm. Guardrails must be at least 865mm in height and permit a 125mm sphere to pass through it.
Barriers and Balustrades
Barriers must be provided where there is a risk of falling from a height of more than 1000mm. Balustrades must be provided where there is a risk of falling from a balcony or other raised platform. Balustrades must be at least 1000mm in height.
Compliance with Building Codes
Stairs and handrails must comply with the Building Code of Australia (BCA) and AS 1657. Compliance with these standards ensures that stairs and handrails are safe and meet the minimum requirements for construction.
Slip Resistance and Safety
Stairs and handrails must be slip-resistant to minimize the risk of slipping and falling. Slip resistance classification must be in accordance with AS 4586. Slip-resistant nosings must be provided on stairs where there is a risk of slipping.
Special Considerations
Special considerations must be taken into account when designing stairs and handrails for people with disabilities. The design must comply with the Disability (Access to Premises – Buildings) Standards 2010.
Frequently Asked Questions
What are the requirements for handrail diameter in Australia?
According to the AS1657-2018 standard, handrails should have a diameter between 30mm and 50mm. The diameter should be consistent along the length of the handrail and provide a secure grip for users.
What is the minimum height for staircase handrails in Australia?
The minimum height for staircase handrails in Australia is 865mm measured vertically from the pitch line or floor. The pitch line is an imaginary line connecting the nosing of all treads in a flight of stairs.
What are the regulations for outdoor steps in Australia?
In Australia, outdoor steps must comply with the same standards as indoor stairs. However, outdoor steps must also be designed to withstand weather conditions and corrosion. Materials used for outdoor steps should be durable and resistant to slip, such as concrete, natural stone, or treated timber.
What is the AS1657 standard and how does it relate to stairs and handrails in Australia?
The AS1657-2018 standard is a set of guidelines for designing and constructing fixed platforms, walkways, stairways, and ladders. The standard outlines the requirements for dimensions, materials, and load capacity for these structures. Compliance with the AS1657-2018 standard is mandatory in Australia.
What are the handrail requirements for industrial settings in Australia?
In industrial settings, handrails must be designed to withstand heavy loads and provide a secure grip for workers. The AS1657-2018 standard requires that handrails in industrial settings have a diameter between 32mm and 50mm and be able to withstand a load of 0.6kN/m.
Is a handrail required for stairs with only 3 steps in Australia?
According to the AS1657-2018 standard, a handrail is not required for stairs with only 3 steps. However, it is recommended that handrails be installed for all stairs to improve safety and accessibility for users.
Wrapping Up
Adherence to Australian standards for stairs and handrails is crucial to ensure safety and compliance in architectural projects. Familiarizing yourself with these standards is essential for responsible design and construction.
